The Main Parameters
Imperial
Metric
Imperial
| Model | FE4P16Q | FE4P20Q |
|---|---|---|
| Series | N Series | N Series |
| Load Capacity Q(lbs) | 3200.0 | 4000.0 |
| Load Center C(in) | 19.7 | 19.7 |
| Operator type | Seated | Seated |
| Overhead Guard Height h6(in) | 81.7 | 81.7 |
| Length to face of Forks l2(in) | 83.9 | 83.9 |
| Overall Width b1(in) | 45.3 | 45.3 |
| Turning Radius (in standard battery compartment) Wa(in) | 78.3 | 78.3 |
| Right Stack Aisle Width for Pallets 1000×1200 | 140.6 | 140.8 |
| Right Stack Aisle Width for Pallets 800×1200 | 148.5 | 1<48.7/td> |
| Tire Type | Pneumatic | Pneumatic |
| Total Approximate Weight (Without battery) (lbs) | 5880.0 | 6360.0 |
| Max. Travel Speed (loaded/unloaded) miine/h | 7.5/8.1 | 6.8/8.1 |
| Li-ion Battery Voltage/Rated Capacity: V/Ah | “48/200 (48/300,48/400)” | “48/200 (48/300,48/400)” |
| Drive Motor- 60 min. rating: hp | 9.4 | 9.4 |
| Pump Motor- 15 min. rating: hp | 11.5 | 11.5 |
| Drive Motor Control Method: | AC | AC |
| Controls: | Curtis | Curtis |
Metric
| Model | FE4P16Q | FE4P20Q |
|---|---|---|
| Series | N Series | N Series |
| Load Capacity Q(Kg) | 1600.0 | 2000.0 |
| Load Center C(mm) | 500.0 | 500.0 |
| Operator type | Seated | Seated |
| Overhead Guard Height h6(mm) | 2075 | 2075 |
| Length to face of Forks l2(mm) | 2130 | 2130 |
| Overall Width b1(mm) | 1150 | 1150 |
| Turning Radius (in standard battery compartment) Wa(mm) | 1990 | 1990 |
| Right Stack Aisle Width for Pallets 1000×1200 Ast (mm) | 3571.0 | 3576.0 |
| Right Stack Aisle Width for Pallets 800×1200 Ast (mm) | 3771.0 | 3771.0 |
| Tire Type | Pneumatic | Pneumatic |
| Total Approximate Weight (Without battery) (kg) | 2940 | 3180 |
| Max. Travel Speed (loaded/unloaded) km/h | 12/13 | 11/13 |
| Li-ion Battery Voltage/Rated Capacity: V/Ah | “48/200 (48/300,48/400)” | “48/200 (48/300,48/400)” |
| Drive Motor- 60 min. rating: kW | 7 | 7 |
| Pump Motor- 15 min. rating: hp | 8.6 | 8.6 |
| Drive Motor Control Method: kW | AC | AC |
| Controls: | Curtis | Curtis |
